Monitoring Metrics AWS
it’s just for monitoring.
1. Amazon Web Services
Amazon EC2
CPUUtilization
The percentage of allocated EC2 compute units currently in use. This metric indicates how heavily the instance CPU is being utilized.
- Unit: Percent (%)
- Statistic: Average, Maximum
Example
- Average CPU utilization remains above 80% for 15 minutes, indicating the instance may be undersized.
- CPU utilization remains below 10% for several days, suggesting potential overprovisioning.
StatusCheckFailed
Reports whether the instance has passed all status checks in the last minute.
This metric can be either 0 (passed) or 1 (failed).
- Unit: Count
- Statistic: Maximum
CloudFront
Requests
The total number of viewer requests received by CloudFront, for all HTTP methods and for both HTTP and HTTPS requests.
- Statistic: Sum
- Unit: None
4xx error rate
The percentage of all viewer requests for which the response’s HTTP status code is 4xx.
- Statistic: Average
- Unit: Percent
Common Status Codes
- 400 Bad Request
- 401 Unauthorized
- 403 Forbidden / Permission Issue
- 404 Not Found
- 429 Too Many Requests
Example: In one hour, there is:
Total Requests = 100,000
404 Errors = 1,000
403 Errors = 500
4xx Errors = 1,500
4xx Error Rate = (1,500 / 100,000) * 100% = 1.5%
Interpretation
| Value | Meaning |
|---|---|
| < 1% | Normal |
| 1% - 5% | Investigate |
| > 5% | Potential issue |
5xx error rate
The percentage of all viewer requests for which the response’s HTTP status code is 5xx.
- Statistic: Average
- Unit: Percent
Common Status Codes
- 500 Internal Server Error
- 502 Bad Gateway
- 503 Service Unavailable
- 504 Gateway Timeout
Interpretation
| Value | Meaning |
|---|---|
| 0% | Ideal |
| < 0.1% | Usually acceptable |
| > 1% | Investigate immediately |
| > 5% | Major outage likely |
Bytes downloaded
The total number of bytes downloaded by viewers for GET and HEAD requests.
- Statistic: Sum
- Unit: None
Bytes uploaded
The total number of bytes that viewers uploaded to CloudFront, using OPTIONS, POST and PUT requests.
- Statistic: Sum
- Unit: None
Monitoring Explanation
If we configure:
- Metric: CPUUtilization
- Time range: Last 7 days
- Statistic: Average
- Period: 1 hour
it means: For each 1-hour interval during the last 7 days, CloudWatch calculates the average CPU utilization of all data points collected within that hour.
Suppose between 09:00 and 10:00 CloudWatch collected these CPU values:
| Time | CPUUtilization |
|---|---|
| 09:00 | 20% |
| 09:05 | 30% |
| 09:10 | 40% |
| 09:15 | 50% |
| … | … |
The average for that 1-hour period might be:
(20 + 30 + 40 + 50 + ...) / number of samples
= 35%
For a 7-day range, we will get: 7 days × 24 hours = 168 data points.
